Zhixing is a professional manufacturer and supplier in China, which has rich experience in the production of C12*9 Ceramic Calibration Board, we have our own processing and production factory, the price is favorable, and we support the customization of various sizes, while ensuring high precision, to meet all requirements of customers, welcome to consult, look forward to working with you.
C12*9 Ceramic Calibration Board is a commonly used optical instrument, it can be used to calibrate cameras, microscopes and other equipment, so as to ensure the quality and accuracy of the image. The following is the use of optical calibration board.
First, prepare an C12*9 Ceramic Calibration Board.
Secondly, the C12*9 Ceramic Calibration Board is fixed on a flat table, and the equipment that needs to be calibrated is placed in the center of the calibration board. Note that the orientation of the device should be consistent with the texture direction of the calibration board.
Then, use the software or tools that come with the device to photograph or observe the pattern on the C12*9 Ceramic Calibration Board. Before shooting or observing, you should ensure that the parameters of the device have been set correctly, such as exposure time, aperture size, focusing distance, etc.
Finally, according to the images taken or observed, the equipment parameters are calibrated. Specific calibration methods can be referred to the equipment manual or related technical papers.
In addition to the above basic use methods, parameters can also be adjusted and optimized according to specific needs, such as adjusting the shooting Angle of the calibration board, increasing or reducing light.
In short, the C12*9 Ceramic Calibration Board is a very practical optical tool, which can greatly improve the image quality and accuracy of the device. When using the device, follow the instructions carefully to ensure correctness and security.
Drawing display
Feature:
|
Pattern size （L*W） |
Square side length | number of squares | material |
Precision (mm) |
| 6*4.5mm | 0.5*0.5mm | 12*9 | glass/ceramics | ±0.001mm |
| 12*9mm | 1.0*1.0mm | 12*9 | glass/ceramics | ±0.001mm |
| 18*13.5mm | 1.5*1.5mm | 12*9 | glass/ceramics | ±0.001mm |
| 24*18mm | 2.0*2.0mm | 12*9 | glass/ceramics | ±0.001mm |
| 36*27mm | 3*3mm | 12*9 | glass/ceramics | ±0.001mm |
| 48*36mm | 4*4mm | 12*9 | glass/ceramics | ±0.001mm |
| 108*81mm | 9*9mm | 12*9 | glass/ceramics | ±0.001mm |
Only some products are shown in the table, if you need other products, you can consult customer service
